Display

Screen diagonal

15 in

19 in

visible area (HxV) in mm

304 x 228

376 x 301

Viewing angle

160° x 160°

160° x 160°

On Screen Display (OSD) configuration

Yes

Yes

Number of colors (bit levels)

16.7 million

16.7 million

Resolution (pixels)

• Resolution (WxH in pixel)

1024 x 768

1280 x 1024

General features

• Brightness/contrast

> 260 cd/m2 / 350:1

> 300 cd/m² / 300:1

• Contrast

250 cd/m² / 300:1

300 cd/m² / 300:1

Control elements

Function keys

No

No

Operating mode

• integrated mouse cursor control

No

No

Installation type/mounting

Rack mounting possible

No

No

Desktop device

No

No

VESA mounting

Yes

Yes

Supply voltage

Type of actuation

AC, DC

AC, DC

• AC

Yes

Yes

• DC

Yes

Yes

permissible range, lower limit (DC)

19.2 V

19.2 V

permissible range, upper limit (DC)

28.8 V

28.8 V

Degree and class of protection

IP20 at front

Yes

Yes

IP54 at front

Yes

Yes

IP65 at front

Yes

Yes

IP20 rear

Yes

Yes

IP54 rear

Yes

Yes

IP65 rear

Yes

Yes

Standards, approvals, certificates

CE

Yes

Yes

CSA

No

No

UL

Yes

Yes

UL approval

Yes

Yes

GL

No

No

ABS

No

No

BV

No

No

DNV

No

No

LRS

No

No

PRS

No

No

Gost-R

No

No

SIBE safety certification

No

No

Dimensions

Width of the housing front

400 mm

483 mm

Height of housing front

310 mm

400 mm
